Performance

GJN-06E-I

GJN-06E-II

Input range (g)

±25

±20

Bias (mg)

≤4

≤4

Temperature sensitivity (µg/℃)

≤30

≤50

One-month composite repeatability (1σ) (µg)

≤30

≤60

Scale factor (mA/g)

1.2~1.6

1.2~1.6

Temperature sensitivity (10-6/℃)

≤40

≤80

One-month composite repeatability (1σ) (10-6)

≤50

≤80

Linearity (µg/g2)

≤15

≤40

Threshold (µg)

<5

<5

Resolution ((µg)

<5

<5

Input voltage (V)

±(12~18)

±(12~18)

Operating temperature (℃)

-45~+70

-45~+70

Weight (g)

≤70

≤70

Environment

Vibration peak sine

20g @ 20~2000Hz

Shock

100g, half-sine, 8 ms~12 ms

Storage temperature

-55~+80℃
