Features
● Small Volume and light Weight
● Analog output
● Environmentally rugged
● Field-adjustable range
● Four fastener precision mounting flanges
● Application in measurement system of oil drilling
|
Performance |
GJN-06K |
|
Input range (g) |
±10 |
|
Bias (mg) |
≤10 |
|
Temperature sensitivity (µg/℃) |
≤150 |
|
Two-hour stability (1σ) (µg) |
≤100 |
|
Scale factor (mA/g) |
2.3~3.5 |
|
Temperature sensitivity (10-6/℃) |
≤150 |
|
Two-hour stability (1σ) (10-6) |
≤100 |
|
Input voltage (V) |
±(12~18) |
|
Operating temperature (℃) |
-40~+125 |
|
Weight (g) |
≤60 |
|
Environment |
|
|
Shock |
1000g, half-sine, 0.5 ms~3 ms |
|
Storage temperature |
-55~+130℃ |
