Product Feature
（1）Integrated Dewar and Cold finger Assembly Design
（2）Standardized Cold Finger Mechanical Interface1/4(in)
（3）Built-out High-precision Drive Controller
Key Specification
(1)Total Cooling Power： 460mW@77K@23℃
280mW@77K@71℃
(2)Typical Cool Down Time： 4min@77K@23℃@200J
5min@77K@71℃@200J
(3)Typical Maximum Input Power ： 16W℃
(4)Typical Steady State Input Power ： 6W℃ (170mW@77K@23℃)
(5)Input Voltage： 12V℃
(6)Cooler Weight： 300g
(7)Cold Finger Diameter： 1/4"
(8)Basic MTTF(hr) ：10000h
(9)Ambient Temperature Range - Operation： -40℃～71℃
Application Field
Temperature above 77K / second-generation focal plane detectors with arrays up to 640×512
