Product Feature
（1）Integrated Dewar and Cold finger Assembly Design
（2）Standardized Cold Finger Mechanical Interface
（3）Built-in High-precision Drive Controller
Key Specification
(1)Total Cooling Power： 650mW@77K@23℃
400mW@77K@71℃
(2)Typical Cool Down Time： 6min@77K@23℃@250J
8min@77K@71℃@250J
(3)Typical Maximum Input Power： 17W℃
(4)Typical Steady State Input Power ： 8W℃(220mW@77K@23℃)
12W℃(220mW@77K@71℃)
(5)Input Voltage： 24V℃/12V℃±0.5V℃
(6)Cooler Weight ：450g
(7)Cold Finger Diameter： 7.6mm
(8)Basic MTTF(hr) ：10000h
(9)Ambient Temperature Range - Operation： -40℃～71℃
Application Field
Temperature above 77K / second-generation focal plane detectors with arrays up to 640×512
