Product Feature
（1）Support custom cold head interfaces
（2）Built-out High-precision Drive Controller
（3）Long lifespan / high cooling capacity / high efficiency / small size / light weight
Key Specification
（1）Total Cooling Power： 15W@77K@23℃
（2）Typical Cool Down Time： 5min@77K@23℃
（3）Typical Maximum Input Power： 280W℃
（4）Typical Steady State Input Power ： 260W℃(15W@77K@23℃)
（5）Input Voltage： 48V℃±2V℃
（6)Cooler Weight： 3.7kg
（7)Cold Finger Diameter： 21mm
（8）Basic MTTF(hr)： 40000h
（9）Ambient Temperature Range - Operation ：-40℃～60℃
Application Field
Applicable to scenarios such as superconducting applications or cryogenic optics
